PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle

I'm Online Chat Now

PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle

China PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle supplier
PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle supplier PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle supplier PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle supplier

Large Image :  PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle

Product Details:

Place of Origin: China
Brand Name: Bondi
Certification: ISO
Model Number: SAN003

Payment & Shipping Terms:

Minimum Order Quantity: 100
Price: 0.98
Packaging Details: standar export carton
Delivery Time: 7days after get your full payment
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 10000pcs/week
Contact Now
Detailed Product Description
Material: Plastic/stainless Steel Spray Pattern: Flat Fan /full Cone/hollow Cone
Product Name: Single Clamp Nozzle

PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle

Clip Eyelet nozzle have got two types: clamp connection type(26988/27988 series) thread connection type,(155series). The clamp connection type nozzle is positioned on the pipe with spring clamp while the thread connection type nozzle is positioned by the way of thread connection. Clamp Eyelet nozzle provides hollow cone spray pattern, solid cone spray pattern and flat fan spray pattern. It meets various needs by directly connecting ball spray tip or by indirectly connecting spray tip with threaded ball or quick dismantling ball. It permits accurate alignment and convenient nozzle positioning without disturbing pipe connection. Clamp Eyelet nozzle allows for quick and easy tip replacement. Spray tips can be removes without the use of tools, removing the existing spray tip by hand and installing the new tip.

Material: GFRP plastic

Pipe/clamp Size: 3/4, 1, 1-1/4, 1-1/2, 2 inch

Drilling Hole Size: 14 mm

Spray Pattern: Flat Fan, Full Cone or Hollow Cone Spray

Resistance Temperature: 82°C Max.

pressure: 4 bar/60PSI

This is a quick connect nozzle, which simply clip on a pre-drilled pipe and are available with a variety of spray tips, in various spray patterns, flow rates and spray angles. Allow for quick and easy replacement Spray tips without the use of tools. Fiberglass reinforced polypropylene with O-ring seal and a 304 stainless steel spring clip. Drill a 9/16”(14mm) hole and attach to pipe. No threads or nipples required, grips the pipe and the body fits in the 9/16” hole. Swivel ball allows for 52° total angle of adjustment

Picture show

PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzlePP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle

PP Adjustable ball clamp spray nozzle for cleaning car water jet nozzle
